Navien NCB500 Combi Boiler
Navien NCB500 Combi Boiler
SKU:ZAP93069
- £25 delivery (excl VAT) or free pickup in store
Couldn't load pickup availability
The Navien NCB500 ON 32kW gas combi boiler offers superb hot water comfort, powerful heating and flexible installation options – making it the ultimate all-rounder for modern family homes. Every model features high quality components to provide exceptional levels of reliability and performance.
Read more
Read more
Key Features
- Easy to use built-in digital display panel displays energy usage.
- Smartphone compatible offering remote adjustments of heating and hot water systems, via app.
- Smart weather forecasting and Geofencing maximise efficiencies and convenience.
- State-of-the-art flow adjustment valve and auto mixing valve for superb hot water comfort.
- Compact dimensions for easy installation in a kitchen cupboard.
- Stainless steel heat exchangers for optimum durability and long term efficiencies.
- IPX4 rating provides protection from any water leaks.
- Shower rating - 1 shower and 1 tap
- Hydrogen-ready (20% blend) technology for futureproofing.
Thanks to Navien ON technology, the ground-breaking Combi Crossover boilers have the power and performance of a system boiler and the advantages of a Combi boiler without the cylinder, eliminating slow heat-up times and low flow rates.
By putting hot water first, Navien's innovative ON technology removes the fluctuation between hot and cold by providing quality, consistent and efficient hot water. With Navien ON, the possibilities are endless.
Warranty
Warranty
Specs
Specs
| Technical Data | 32 kW | 37 kW | 41 kW | |
|---|---|---|---|---|
| Shower rating | Number of showers | 1 shower & 1 tap | 2 Showers | 2 Showers & 1 tap |
| Heat Output | Heat input range | 26.8/4.6kW | 26.8/4.6kW | 26.8/4.6kW |
| Modulation (max/min) | 6:1 | 6:1 | 6:1 | |
| Heat output range @ 80/60°C | 26.0/4.5kW | 26.0/4.5kW | 26.0/4.5kW | |
| DHW | DHW heat input range | 32.0/4.6kW | 37.0/4.6kW | 41.0/4.6kW |
| DHW output range | 32.0/4.6kW | 37.0/4.6kW | 41.0/4.6kW | |
| DHW flow rate @ 25°C temp. rise. | 18.4 l/min | 21.3 l/min | 23.6l/min | |
| DHW flow rate @ 35°C temp. rise. | 13.1l/min | 15.2l/min | 16.8l/min | |
| DHW flow rate for kitchen @ 45°C temp. rise. | 10.2l/min | 11.8l/min | 13.1l/min | |
| Modulation | TDR | 7:1 | 8:1 | 9:1 |
| Flue | Flue Size | Coaxial length Ø 60/100 | ||
| Max. horizontal coaxial length Ø60/100 | 8m | |||
| Max. vertical coaxial length Ø60/100 | 8m | |||
| Weight | Lift weight | 34kg | 34kg | 34kg |
| Dimensions | Width x Depth x Height | 395 x 285 x 680mm | ||
| ErP Efficiency | ErP A (93%) | |||
| ErP Efficiency with Smart Plus (x3) | ErP A+ (98%) | |||
| NOx Classification | Class 6 | |||
